You can also select what object in the data object to select or delete. The data options to choose from are based on what is in the project. In the Select/Delete Data dialog, choose whether to select or delete the data and which data the function should be applied to.Removing a load breaks its association with the rigging. Select the Feature Objects | Select/ Delete Data menu command. You can remove loads from rigging objects in the model and in schematic views.Select the polygon using the Select Polygon tool.Next, build a polygon using the Feature Objects | Build Polygons menu command if you are not using an existing polygon.After locating the area that needs to be altered, use the Create Feature Arc tool to enclose the desired area or use an existing polygon.Only a few steps are needed in order to use the Select/ Delete Data tool. Furthermore, the tool can be used to delete objects inside the select polygon. This can go quickly if you already have the desired polygon created on a map coverage, such as a materials coverage. It can also be used for selecting points or triangles in a scatter set or feature objects on a different map coverage. The Select/ Delete Data tool uses a polygon in the Map module to select objects in a grid, or mesh.
However, another option is to use the Select/Delete Data tool in SMS. Other selection tools, such as the Select by Poly tool, could be used. This could be very time consuming in a large mesh or grid.
One option is to change the attributes directly within an already established mesh or grid by selecting individual cells, elements, or nodes. In order to accomplish either of this, there are a couple of options. Do you have a project that requires selecting a specific region of a mesh or grid to properly gather the necessary data for that area? For example, perhaps you need to select the mesh elements in the area of a bridge so that the elements can be refined.
